50 WATT MOSO X6E-050M072TD | 50W Programlanabilir IP67 LED Driver

MOSO X6E-050M072TD | 50W Programlanabilir IP67 LED Driver

MOSO X6E-050M072TD, profesyonel dış mekân aydınlatmaları için geliştirilmiş 50W programlanabilir sabit akım LED driver modelidir. 176–305V AC giriş aralığı ve yüksek güç faktörü (PF 0.96) ile enerji verimliliği ve şebeke uyumu sağlar. 0-10V ve PWM dimleme desteği, ışık seviyesinin hassas şekilde kontrol edilmesine olanak tanır.

IP67 koruma sınıfı, sürücüyü toz, nem ve suya karşı tam koruma altına alır. Aşırı gerilim, kısa devre, aşırı sıcaklık ve yıldırım darbesine karşı gelişmiş koruma özellikleri sayesinde uzun ömürlü ve güvenli kullanım sunar. Yol, sokak, tünel, endüstriyel ve projektör aydınlatmaları için ideal tercihtir.

50 WATT X6E 50W Programmable Driver

The X6E series is outdoor programmable LED driver that operates in constant current with high PF value and full power input voltage range 176~305Vac model, the X6E series also provide multiple isolated dimming controls, Dim-to-Off. It also helps clients to improve the management of logistics and stock. The compact metal case and high efficiency enable the driver to operate with high reliability. It provides extreme durability with an IP67 rating and extends product lifetime. Overall protection is provided against lightning surge, output over voltage, short circuit and over temperature to ensure low failure rate.

• Universal input voltage / Full range: 90~305Vac;
• Isolate constant power design
• Constant power design, output current programming adjustable;
• (Mtypes) off-line programmable, (V types) output current adjustable by built-in potentiometer;
• 3-in-1 dimmable: 0~10Vdc, PWM, Positive and negative logic, Timer dimming,
• Programmable Constant Lumen Output (CLO)
• Self adapting-midnight dimming;
• Output and Dimming Signal Isolating;
• Surge protection: 6KV line-line, 10KV line-earth;
• Protections: input / UVP output SCP, OVP, OTP;
• IP67design for indoor and outdoor applications;
• Suitable for dry / damp / wet locations;
• 5years warranty. Application
• Suitable for LED roadway lighting, industrial lighting, landscape lighting, etc
• Application
  Road and street lighting,
  Tunnel lighting Area and flood lighting High-bay lighting

  Model Number	InputVoltage Range (Vac)	MAX Output Power (W)	Output Voltage Range (Vdc)	Full Power Output Current Range (A)	Default Current(A)	Eff. (Typ.)	PF(Typ.)	THD(Typ.)
  X6E-50M072TD	176~305	50	35 - 72	0.7 - 1.05	0.70	88%	0.96	5%





   NOTES:
   [1]. M means 0-10V/PWM dimming.
   [2]. All specifications are measured at 25℃ ambient temperature, input voltage 230Vac, and the typical value tested by full load, if no specific note.

Güç	50 W
Koruma ve Sızdırmazlık Seviyesi	IP67 (Tam Dış Mekan / Su Geçirmez)
Teknik	Dimlenebilir , Seçmeli Akım
